While in motion, frequencies between 700-1,400 Hz typically run up the cone of a woofer and are reflected back and forth from the center of the driver. This creates unwanted harmonic distortion. The X-Wave surround found in Origin woofers absorbs these frequencies reducing distortion and maintaining driver stability. This design also maximizes cone area by reducing the width of the surround.
As the driver travels to the limits of its excursion, the suspension, made up of the spider and the surround, becomes more rigid, exerting more control on the movement of the cone. The result is increased, clean power output throughout the driver‘s frequency range.
Utilizing the latest techniques and materials in plastic fabrication, Origin is able to create basket designs with superior stability and acoustic neutrality. These baskets combine with the driver suspension to increase linearity and improve overall performance.
Building on the success of Origin Acoustics‘ patented mounting system, the Bang & Olufsen Palatial™ features Spring-Lock™ 2.0 Tool-Less Mounting System. The speakers mount effortlessly and remain completely secure over time. (Patent #9366380)
|Cut Out Depth||3.78|
|Cut Out Width||7.875|
|Cut Out Height||29|
|Speaker Width (in.)||8.67|
|Speaker Height (in.)||29.85|
|Frequency Response||40 Hz - 20 kHz|
|Mounting Hardware Included||Yes|
|RMS Power Handling (Watts)||10|
|Enclosure Type||Compression-Molded Basket|
|Number of Speakers||1|
|Speaker Type||In-Wall Speakers|
