Klipsch® Raw Birch Single 15" Subwoofer
$1,549.00
At a Glance
Designed for high output, long-term reliability, the Klipsch KI-115-SMA-II low frequency enclosure utilizes a single K-48-ST cast frame 15” woofer. This 104-ounce magnet, 3” voice coil powerhouse delivers high sensitivity with superior power handling. Klipsch’s specially designed speaker motor assembly ensures that high transient cone excursions won’t damage the voice coil former under extreme output applications.
Proposition 65 Warning for California Residents
General Specs
| Product Weight (lbs.) | 62 |
|---|---|
| Color | Beige |
| Depth (in.) | 19.2 |
| Width (in.) | 24.6 |
| Height (in.) | 18.5 |
| Speaker Type | Powered Subwoofers |
| MPN | 1062013 |
| Color Finish Name | Raw Birch |
| RMS Power Handling (Watts) | 1600 |
| Subwoofer Size | 13+ |
Specifications
| Frequency Response | 49 Hz - 200 kHz (-10 dB @ 35 Hz) |
|---|---|
| Power Handling | 400 watts (44.7V); 1600 watts peak |
| Maximum SPL | 124 dB Continuous; 130 dB Peak |
| Sensitivity | 101 dB |
| Nominal Impedance | 8 ohms, minimum 5 ohms @ 39 Hz |
| Components | One K-48-ST 15” woofers |
| Input Connection | Two point barrier strip |
| Mounting Options | Four 3/8”-16 flypoints |
| Enclosure Material | 3/4" 7-ply birch plywood cabinet |
| Height | 18.5” (46.99cm) |
| Width | 24.6” (62.48cm) |
| Depth | 19.2” (48.77cm) |
| Weight | 62 lbs. (28.18kg) |
| Finishes | Black, White and Raw Birch |
Klipsch® Raw Birch Single 15" Subwoofer
Model #: KI-115-SMA-II-Raw Birch
$1,549.00
At a Glance
Get to know this product.
Perfect for music reinforcement and reproduction, the KI-115 finds ready application in clubs, theaters, auditoriums, churches and performance environments. The rugged, tuned port, 3/4” furniture grade plywood enclosure utilizes CNC fabrication techniques for uniform tolerances, contributing to advanced reliability and ruggedness. Dado “locktab” and rabbet joint construction contribute to freedom from resonance and cabinet-induced coloration.
The KI-115-SMA-II utilizes four 3/8"-16 suspension points, located on the rear of the enclosure, to support suspended applications in a "face-down" orientation.
Features
High power 15” low frequency speaker system
Compatible with Klipsch KI-102-SMA-II, KI-172-SMA-II, KI-262-SMA-II, and KI-272-SMA-II speaker models
Specially designed motor assembly assure high transient cone excursions do not harm the voice coil under extreme out application
Four suspension points on the back of cabinet (face down orientation only)
124 dB SPL maxmium output
Available in Black, White or Raw Birch finish
