Leveraging a 1" aluminum tweeter matted to our proprietary Tractrix horn-loaded technology - the R-51M bookshelf speaker delivers incredible acoustics to fill your home with loud, crystal-clear sound and robust bass that no ordinary bookshelf speaker can.
Connector Type | Single Gold Plated Binding Posts |
---|
Crossover Type | 1,660 Hz |
---|---|
Sold As | Pair |
Enclosure Type | Bass-Reflex Via Rear-Firing Ports |
---|---|
Tweeter Composition | Aluminum |
Woofer Composition | IMG (Injection Molding Graphite) |
Product Weight (lbs.) | 11 |
---|---|
MPN | 1065839 |
Color Finish Name | Black |
RMS Power Handling (Watts) | 340 |
Color | Black |
Impedance | 8 ohms |
Number of Speakers | 1 |
Speaker Type | Bookshelf Speakers |
Depth (in.) | 8.5 |
Height (in.) | 13.3 |
Width (in.) | 7 |
Frequency Response | 62Hz - 21kHz +/- 3dB |
---|---|
Sensitivity | 93 dB @ 2.83V/1M |
Power Handling (Cont/Peak) | 85W/340W |
Nominal Impedance | 8 ohms Compatible |
Crossover Frequency | 1,660 Hz |
High Frequency Driver | 1” Aluminum LTS tweeter mated to a 90 x 90 square Tractrix® Horn |
Low Frequency Driver | Single 5.25” spun-copper IMG woofer |
Enclosure Material | MDF |
Enclosure Type | Bass-Reflex via rear-firing ports |
Inputs | Single Gold Plated Binding Posts |
Height | 13.3” (338 mm) |
Width | 7” (178 mm) |
Depth | 8.5” (215 mm) |
Weight | 11 lbs (5 kg) |
Finish | Black Textured Wood Grain Vinyl |
Included Accessories | Rubber Feet (4) |
Built From | 2018 |
1" Aluminum LTS tweeters
90x90 Square Tractrix Horns
Dual 5.25" Spun-Copper IMG Woofers
Bass-Reflex via Rear-Firing Port
Strong, Flexible Removable Magnetic Grille
Dimensions: 13.3" x 7" x 8.5"
Klipsch exclusive 90x90º Tractrix® horn technology ensures that the R-51M high frequency energy is aimed at the listener and reduces artificial reverb or filtering caused by indirect sound bouncing off of walls. Using this proprietary focused technology gives you the best clarity, dynamics, and detail from your movies and music.
Klipsch exclusive Linear Travel Suspension (LTS) aluminum tweeter minimizes distortion for enhanced, detailed performances. Using Kapton®, an extremely light and rigid material, in the tweeter suspension provides high efficiency and improve resolution and detail. LTS tweeters are a hallmark of Klipsch speakers, making them some of the best speakers in the world.
Injection Molded Graphite (IMG) woofer cones are exceptionally light while being extremely rigid – providing remarkable low frequency response, with minimal cone breakup and distortion. When paired with the Tractrix Horn-Loaded LTS Tweeter, it provides speaker efficiency highest in its class.
Exposed fasteners, low profile magnetic grilles and a scratch-resistant, textured wood grain vinyl give the R-51M bookshelf speakers a polished, modern appearance.
Reinforced MDF construction reduces cabinet vibration for less audible coloration and improved sonic accuracy - giving you the ultimate listening experience that's built to last.
Product Weight (lbs.) | 11 |
MPN | 1065839 |
Color Finish Name | Black |
RMS Power Handling (Watts) | 340 |
Color | Black |
Impedance | 8 ohms |
Number of Speakers | 1 |
Speaker Type | Bookshelf Speakers |
Depth (in.) | 8.5 |
Height (in.) | 13.3 |
Width (in.) | 7 |
Connector Type: | Single Gold Plated Binding Posts |
Enclosure Type: | Bass-Reflex Via Rear-Firing Ports |
Tweeter Composition: | Aluminum |
Woofer Composition: | IMG (Injection Molding Graphite) |
Crossover Type: | 1,660 Hz |
Sold As: | Pair |
Frequency Response | 62Hz - 21kHz +/- 3dB |
Sensitivity | 93 dB @ 2.83V/1M |
Power Handling (Cont/Peak) | 85W/340W |
Nominal Impedance | 8 ohms Compatible |
Crossover Frequency | 1,660 Hz |
High Frequency Driver | 1” Aluminum LTS tweeter mated to a 90 x 90 square Tractrix® Horn |
Low Frequency Driver | Single 5.25” spun-copper IMG woofer |
Enclosure Material | MDF |
Enclosure Type | Bass-Reflex via rear-firing ports |
Inputs | Single Gold Plated Binding Posts |
Height | 13.3” (338 mm) |
Width | 7” (178 mm) |
Depth | 8.5” (215 mm) |
Weight | 11 lbs (5 kg) |
Finish | Black Textured Wood Grain Vinyl |
Included Accessories | Rubber Feet (4) |
Built From | 2018 |
